BSWF led frame moving head 800w 1000w 1200w 1400w optional

BSWF led frame moving head 800w 1000w 1200w 1400w optional

LED profile moving head light designed for exceptional stage performance. With advanced CMY and CTO capabilities, this lighting solution delivers versatile color mixing and precision control, making it ideal for professional event productions. Experience superior lighting quality with Vanray's industry-leading innovation.

LED profile moving head light

Model: VR-850

Input voltage: AC100-240V,50/60Hz

Power rate: 850W

Light source: LED energy-saving module 800W（selectable 1000W.1200W.1400W）

LED life: 30,000 hours

Color temperature: 7200K

Color rendering index: Standard mode Ra>75, high display mode Ra>90

Luminous flux: 24000LM

Control mode: DMX512, RDM

Channel mode: 36 international standard DMX512 channels

Display system: 2.5-inch touch LCD, Chinese and English display, 180 degree rotation

Fixed color: 7 colors + white light

Color mixing system: Independent CMY color mixing system

Color temperature adjustment: Independent CTO2800-6000K linear adjustment

Prism : Rotate 4 prisms +4 rows of mirrors

Effect tray: Super dazzling simulation of dynamic flames, gurgling water and other dynamic effects

Fixed gobo: 8 fixed pattern pieces + white circle

Rotating gobo: 7 pieces (removable) outer diameter 27.9mm, effective diameter 16.5mm, thickness 1.1mm

Profile system: 4 independent cutting pieces, each piece can be individually closed light, can be rotated 90°

Atomization system: 0~100% linear atomization

Aperture system: 5%~100% smooth adjustment

4-in-1 optical lens design: (BEAM mode) : 2° ~ 6°; (SPOT pattern mode) : 10° ~ 48°; (WASH dyeing mode) : 0° ~ 52° Four modes can be arbitrarily switched to achieve light beam, dyeing, pattern, cutting four in one function.

Dimming system: 0-100% linear adjustment

Stroboscopic system: The frequency can reach up to 25Hz, and can choose random stroboscopic and pulse stroboscopic

Horizontal scan: 540° (16 bit precision scan)

Vertical scan: 270° (16 bit precision scan)

IP rating: IP20

Working environment: 0-45℃

Product size: 434*320W*759H(mm)

Net weight: 35kgs
