Waterproof laser Beam moving head light VF-JG260

VANRAY Laser Beam Moving Head VF-JG260 Waterproof Laser Beam Light

With a high-end appearance, immense power, and thick light beam, this waterproof beam light excels in optical, structural, and aesthetic performance, reaching high standards. It adopts the latest high-brightness laser light source technology, optical technology, and rigorous industrial design to ensure the perfect presentation of the lighting design.

Waterproof laser Beam moving head light VF-JG260

1. Wide Voltage: AC90V-235V 50-60Hz

2. Wide Voltage Drive Power Supply: 600W

3. Light Source System: 260W Laser Light Source

4. Color Temperature: 7900±500K

5. Color System: Color wheel: 24 color segments + white light + six-color rainbow effect (optional addition of CMY system)

6. Pattern System: Pattern wheel: 17 fixed patterns + 1 white light

7. Focusing System: Electronic focusing

8. Fogging System: Equipped with fogging function, capable of achieving soft light effect

9. Strobe: Independent strobe effect, 0.5 - 20 times per second, adjustable speed

10. Motor: XY axes use three-phase motors, ensuring high stability in speed and precise positioning angles for the lamp

11. Dimming Curve: 0% - 100% linear dimming, smooth without flicker

12. Beam Angle: 0 - 2°

13. Channels: 16 channels

14. Outer Lens Diameter: 176mm

15. Waterproof Rating: IP65

16. Control Method 1: DMX 512, self-run, master-slave self-run, RDM function

17. Prism System: Composed of 8 prisms and honeycomb (8 + 16) prisms, can be stacked

18. Display Screen: LCD display screen, adaptable to different installation positions, rotatable 180°

19. Horizontal and Vertical: Utilizes high-precision three-phase motors, accurate positioning, smooth operation, and automatic positioning correction

20. Horizontal: 540° rotation, resolution 8/16Bit, with fine-tuning

21. Vertical: 270° rotation, resolution 8/16Bit, with fine-tuning.

22. Cooling System: Lamp body cooling combined with intelligent fan air diversion cooling system, using software to analyze and calculate the heat flow of the lamp, quickly dissipating internal heat, extending the lifespan of the light source, ensuring the bulb's service life, and featuring a low-noise cooling system fan with excellent driving performance and extremely low noise.

23. Cast aluminum + outdoor engineering plastic housing

24. Installation Method: Upright / inverted

25. Lamp Body Dimensions: 360*292*623mm

Net Weight: 23.5KG,
