VANRAY LED Profile Moving Head 1000W with CMY and CTO

welcome back to vanray lighting , this video is talk about 1000w led profile moving head , its under the final test , it has 7 colors and 7 rotation gobos , with cmy and cto function , for cutting function , it has 4 independent cutting piece which can rotated in 90degrees .

Model: VR-850

Input voltage: AC100-240V,50/60Hz

Power rate: 850W

Light source: LED energy-saving module 800W（selectable 1000W.1200W.1400W）

LED life: 30,000 hours

Color temperature: 7200K

Color rendering index: Standard mode Ra>75, high display mode Ra>90

Luminous flux: 24000LM

Control mode: DMX512, RDM

Channel mode: 36 international standard DMX512 channels

Display system: 2.5-inch touch LCD, Chinese and English display, 180 degree rotation

Fixed color: 7 colors + white light

Color mixing system: Independent CMY color mixing system

Color temperature adjustment: Independent CTO2800-6000K linear adjustment

Prism : Rotate 4 prisms +4 rows of mirrors

Effect tray: Super dazzling simulation of dynamic flames, gurgling water and other dynamic effects

Fixed gobo: 8 fixed pattern pieces + white circle

Rotating gobo: 7 pieces (removable) outer diameter 27.9mm, effective diameter 16.5mm, thickness 1.1mm

Profile system: 4 independent cutting pieces, each piece can be individually closed light, can be rotated 90°

Atomization system: 0~100% linear atomization

Aperture system: 5%~100% smooth adjustment

4-in-1 optical lens design: (BEAM mode) : 2° ~ 6°; (SPOT pattern mode) : 10° ~ 48°; (WASH dyeing mode) : 0° ~ 52° Four modes can be arbitrarily switched to achieve light beam, dyeing, pattern, cutting four in one function.

Dimming system: 0-100% linear adjustment

Stroboscopic system: The frequency can reach up to 25Hz, and can choose random stroboscopic and pulse stroboscopic

Horizontal scan: 540° (16 bit precision scan)

Vertical scan: 270° (16 bit precision scan)

IP rating: IP20

Working environment: 0-45℃

Product size: 434*320W*759H(mm)

Net weight: 35kgs
